710-1016-01-0
FLEXpro16
Model
710-1016-01-0flex
FLEXpro16
FLEXpro for professional AV workflows and seamless integration
PROAVvideo scalersvideo switchersvideowall controllers
Product Overview
Understand this product quickly
Designed to streamline signal management in live and installed environments, supports versatile source connections, delivers flexible display routing, offers standard industry interfaces for integration, provides scaling, switching and control capabilities as specified, operates with the supplied power configuration, FLEXpro16: 4U host (including local communication module and single power supply, input and output modules are optional) A total of 9 slots: support 4 input cards, 4 output cards, 1 pre-monitoring card, standard single power supply.
SKU and Configuration
Models and options
Input option4
790-1016-01-0
Quad HDMI 1.3 Input Module
Input option
790-1016-03-0
Quad 3G-SDI Input Module
Input option
790-1016-02-0
Dual DP 1.2 + Dual HDMI 2.0 Input Module
Input option
790-1016-04-0
Single IP Input Module
Input option
| 790-1016-01-0 | Quad HDMI 1.3 Input Module | Input option | |
| 790-1016-03-0 | Quad 3G-SDI Input Module | Input option | |
| 790-1016-02-0 | Dual DP 1.2 + Dual HDMI 2.0 Input Module | Input option | |
| 790-1016-04-0 | Single IP Input Module | Input option |
Output option3
790-1016-22-0
Quad HDMI 1.3 Output Module
Output option
790-1016-25-0
Quad SDI Output Module
Output option
790-1016-24-0
Dual HDMI 2.0 Output Module
Output option
| 790-1016-22-0 | Quad HDMI 1.3 Output Module | Output option | |
| 790-1016-25-0 | Quad SDI Output Module | Output option | |
| 790-1016-24-0 | Dual HDMI 2.0 Output Module | Output option |
Comm option1
790-1016-23-0
Communication Module with PVW
Comm option
| 790-1016-23-0 | Communication Module with PVW | Comm option |
Preview option1
790-1016-21-0
Dante/AES67 PVW Module
Preview option
| 790-1016-21-0 | Dante/AES67 PVW Module | Preview option |
Power Supplies1
950-0014-01-0
PSU 250W
Power Supplies
| 950-0014-01-0 | PSU 250W | Power Supplies |
